光固化涂料 curing coatings
● 产品特点及用途Characteristics and applications
1.施工简单:可一次性成型200-300µm,漆膜光亮丰满,不用打磨抛光。
Simple operation :Can one-time forming with 200-300µm coating, without grinding and buffing, the paint film is shiny and plump.
2. 固化速度快,生产效率高:采用光固化工艺,几十秒内即可包装。
Faster curing rate, Higher productivity:using Stereo lithography Appearance, can packaging in a few seconds.
3. 成本低:200µm的材料成本仅为8元/㎡,省时省工省场地。
Low cost:The 200µm of material costs 8 /㎡ only, save time 、save energy、 save space.
4. 绿色环保:不含三苯溶剂,溶剂挥发少。
Environmental-friendly: No triphenyl solvent,low volatility.
5. 综合性能优异,适用于腰线等曲面材料上的施工,可实现自动化生产。
Excellent comprehensive performance,can achieve automatic manufacturing,suitable for construction on curved surface material such as waist line, etc.

● 性能指标Property index

项目 检测方法 技术指标
Items Test method Index
外观 目测 浅黄透明液体
Appearance visual Light Yellowish Transparent Liquid
粘度 GB/T 7193 20~30
Viscosity s/25℃
固体含量 GB/T 7193 50~56
Non-Volatile    %
漆膜硬度 GB 6379 3
Film hardness   H ≥
柔韧性 GB/T 1731 2
Suppleness     mm ≤
附着力 GB 9268 1
Adhesion 级 ≤
光泽度 GB/T 9754 90
Surface gloss    % ≥
